Hight frequency X-Ray unit eliminates soft radiation: Allowing doctors and patients to suffer less radiation than conventional equipment
Error code display function: Pre-set digital imaging modes with adjustable parameters provide opportunities to use digital image systems and its compatible with digital image sensors from any brands
Excellent stability: Stable operation, fast and accurate positioning, independent of fixed voltage, no need for voltage regulator
Reduced exposure time: Higher radiation safety standards and longer tube life
Precise timing control: The unit incorporates microprocessor technologies to search the exposure time precision of 1/100 seconds. Numerical designs indicate timely and correctly for any warnings or alarms.
Product Parameter:
Power Voltage:AC 110V-240V
Bulb Tube: Canon (Toshiba)
Duty Cycle:1/30
Frequency:50/60Hz
Ray Focal Spot:0.4mm
Half Value Layer:65Kv
Maximum Power:1100VA
Bulb Tube Voltage:65Kv±10%
Inherent Filtration:≥2.1mm Al
Electricity:5A
Anode Current:7mA±20%
Leakage Radiation:1meter≤ 0.14mGy/h
Fuse:10A
Anode Angle:12.5°
Time Of Exposure:0.04—2.0s
DC X-Ray 98(W)
$
1750
$
2000
BUY NOW
Portable type X-Ray.
Hight frequency X-Ray unit eliminates soft radiation: Allowing doctors and patients to suffer less radiation than conventional equipment
Almost no soft rays and stray radiation, high imaging quality
Error code display function: Pre-set digital imaging modes with adjustable parameters provide opportunities to use digital image systems and its compatible with digital image sensors from any brands
Excellent stability: Stable operation, fast and accurate positioning, independent of fixed voltage, no need for voltage regulator
Reduced exposure time: Higher radiation safety standards and longer tube life
Precise timing control: The unit incorporates microprocessor technologies to search the exposure time precision of 1/100 seconds. Numerical designs indicate timely and correctly for any warnings or alarms.
Product Parameter:
Power Voltage:AC 110V-240V
Bulb Tube: Canon (Toshiba)
Duty Cycle:1/30
Frequency:50/60Hz
Ray Focal Spot:0.4mm
Half Value Layer:65Kv
Maximum Power:1100VA
Bulb Tube Voltage:65Kv±10%
Inherent Filtration:≥2.1mm Al
Electricity:5A
Anode Current:7mA±20%
Leakage Radiation:1meter≤ 0.14mGy/h
Fuse:10A
Anode Angle:12.5°
Time Of Exposure:0.04—2.0s
DC X-Ray 98(P) with stand
$
1250
$
1500
BUY NOW
Features:
A true high frequency chair side x-ray machine, ensures less radiation for the patient & operator with high resolution images.
The circuit components imported from South Korea adopt high frequency closed-loop control; lmaging will not be affected even if the battery power is low.
Adopt Canon micro focus tube with focus 0.4mm,anode angle of 125
Less exposure time only about 0.4S, which is 5-8 time shorter than ordinary portable x-ray, less radiation dose,and avoid hand shake causing the blurry image
Light in weight,only 1.7 kgs. Compact & single handed operational device
